Home›Brands›Xiaomi›Xiaomi 17 Pro Max

Xiaomi · Full Phone Specifications

Xiaomi 17 Pro Max

Name: Xiaomi 17 Pro Max
Brand: Xiaomi

RAM 12GB RAM / 16GB RAMROM / Storage 512GB, 1TBBattery 7500mAh

AvailableReleased: 2025-09-25Announced: 2025-09-25

Check Phone Value Compare More Xiaomi Phones

Specifications are presented for informational purposes. Always verify regional model numbers and official manufacturer specifications before purchase.

Key Specs

Xiaomi 17 Pro Max

Display6.9 inches, 116.6 cm2 (~92.3% screen-to-body ratio)

ChipsetQualcomm SM8850-AC Snapdragon 8 Elite Gen 5 (3 nm)

RAM12GB RAM / 16GB RAM

Storage512GB, 1TB

Main Camera50 MP, f/1.7, 23mm (wide), 1/1.28", 1.22µm, dual pixel PDAF, OIS; 50 MP, f/2.6, 115mm (periscope telephoto), 1/1.95", 0.8µm, PDAF (30cm - ∞), OIS, 5x optical zoom; 50 MP, f/2.4, 17mm, 102˚ (ultrawide), 1/2.88", 0.61µm, PDAF

Battery7500mAh

LAUNCH

Launch

Status

Available

Announced

2025-09-25

Release Date

2025-09-25

NETWORK

Network

Technology

GSM / HSPA / LTE / 5G

GSM 850 / 900 / 1800 / 1900

HSDPA 800 / 850 / 900 / 1700(AWS) / 1900 / 2100

1, 2, 3, 4, 5, 7, 8, 12, 13, 17, 18, 19, 20, 25, 26, 28, 34, 38, 39, 40, 41, 42, 48, 66, 71

1, 2, 3, 5, 7, 8, 12, 13, 18, 20, 25, 26, 28, 38, 40, 41, 48, 66, 70, 71, 77, 78, 79, 80, 81, 83, 84, 89 SA/NSA

Sim

Nano-SIM + Nano-SIM

BODY

Body

Dimensions

162.9 x 77.6 x 8 mm (6.41 x 3.06 x 0.31 in)

Weight

219 g (7.72 oz)

Build

Glass front (Dragon Crystal Glass 3), aluminum frame

Ip Rating

IP68 dust tight and water resistant (immersible up to 6m for 30 min

DISPLAY

Display

Type

LTPO AMOLED, 68B colors, 2160Hz PWM, 120Hz, Dolby Vision, HDR Vivid, HDR10+, 3500 nits (peak)

Size

6.9 inches, 116.6 cm2 (~92.3% screen-to-body ratio)

Resolution

1200 x 2608 pixels, 19.5:9 ratio (~416 ppi density)

Refresh Rate

120Hz

Protection

Xiaomi Dragon Crystal Glass 3

Hdr

HDR10+, HDR10, Dolby Vision

PLATFORM

Platform

Android 16, HyperOS 3

Chipset

Qualcomm SM8850-AC Snapdragon 8 Elite Gen 5 (3 nm) ↗

Cpu

Octa-core (2x4.6 GHz Oryon V3 Phoenix L + 6x3.62 GHz Oryon V3 Phoenix M) ↗

Gpu

Adreno 840 ↗

MEMORY

Memory

Ram

12GB RAM / 16GB RAM

Storage Options

512GB, 1TB

Card Slot

CAMERA

Main Camera

Main

50 MP, f/1.7, 23mm (wide), 1/1.28", 1.22µm, dual pixel PDAF, OIS; 50 MP, f/2.6, 115mm (periscope telephoto), 1/1.95", 0.8µm, PDAF (30cm - ∞), OIS, 5x optical zoom; 50 MP, f/2.4, 17mm, 102˚ (ultrawide), 1/2.88", 0.61µm, PDAF

Selfie

50 MP, f/2.2, 21mm (wide), 1/2.88", 0.61µm, PDAF

Video

8K@30fps (HDR), 4K@30/60/120fps (HDR10+, 10-bit Dolby Vision HDR, 10-bit LOG), 1080p@30/60/120/240/960fps, 720p@1920fps, gyro-EIS

Periscope

50 MP, f/2.6, 115mm (periscope telephoto), 1/1.95", 0.8µm, PDAF (30cm - ∞), OIS, 5x optical zoom;

Ultrawide

50 MP, f/2.4, 17mm, 102˚ (ultrawide), 1/2.88", 0.61µm, PDAF

SOUND

Sound

Loudspeaker

Yes, with stereo speakers

Audio Jack

COMMS

Communications

Wlan

Wi-Fi 802.11 a/b/g/n/ac/6e/7, dual-band, Wi-Fi Direct

Bluetooth

5.4, A2DP, LE, aptX HD, aptX Adaptive, LHDC 5

Nfc

Yes

Usb

USB Type-C 3.2, Display Port, OTG

Gps

GPS (L1+L5), BDS (B1I+B1c+B2a), GALILEO (E1+E5a), QZSS (L1+L5), NavIC (L5), GLONASS

FEATURES

Features

Sensors

Fingerprint (under display, ultrasonic), accelerometer, proximity, gyro, compass, barometer

Water Resistance

IP68 dust tight and water resistant (immersible up to 6m for 30 min)

Biometrics

Fingerprint (under display

BATTERY

Battery

Capacity

7500mAh

Charging

100W wired, PD3.0, QC3+, 100W PPS; 50W wireless; 22.5W reverse wireless

Wireless Charging

50W wireless

Available Colors

BlackWhitePurpleGreen

Model Numbers

2509FPN0BC
